Copper recycling machine
recycling machine
Henan Doing company copper recycling machine is the equipment that separating the scrap wire metal and plastic. Because the final products are similar to rice particles, so this copper recycling machine is also called copper wire granulator.
Henan Doing copper recycling machine can completely separate the copper and plastic, and realize the integrated utilization. Further, the wire recycling machine has the features of higher economic benefits, no dust and no secondary pollution.
Copper recycling machine raw material

copper recycling machine

Copper recycling machine is a kind of waste copper cable wire recycling machine, this machine can process telephone wires, computer wires,  automobile  wires, tele communication cables, etc
Copper recycling machine working process
copper recycling machine
Working process of copper recycling machine
When directly put into the copper  recycling machine, used cable is cut into granules first, during this process, copper and plastic is separated but mixed together, then the granules are sent to vibration device for separation, through wind blow and vibration, the copper and plasticis are separated, then pure copper comes out fromone side and pure plastic comes out from the other side, we collect the separated pure copper and non-meatal.

Copper recycling machine technical data


Item Model Capacity(kg/h) Power(Kw) Size (m)(L*W*H) Weight(T) Remark
1 DY-400 100-200 28.5 3.5×1.5×3.0 1.8
2 DY-600 300-500 36.5 4.0×1.7×3.0 3.0
3 DY-800 500-800 90.0 4.5×1.5×4.2 7.7 Doubling crushing system
4 DY-1000 800-1000 104.2 4.8×1.8×4.2 9.4 Doubling crushing system

Copper recycling machine feature
recycling copper
Feature of copper recycling machine
1.Suitable structure and layout, easy to install.

2. PLC system makes it easier to control the whole line, convenient to feed and operate.

3. The design of separator and dust collector is handy for movement or transport.

4. The rotor of the grinder is alternating, leading to more efficiency, faster discharging, low noise and steadier running.

5. Feedback system will do the second crushing to the unfinished material, which guarantees the total separation of metal and non-metal.

6. The separation rate of air separator can reach at least 99%.

7. Dust collector can prevent the leak of dust. The dust cleaning rate can reach 99.99%.



Copper recycling machine final product

copper recycling machine
