1.Waste wire recycling machine brief introduction
Waste wire recycling machine
Waste wire recycling machine, also called scrap electric wire and cable recycling equipment, copper wire separator, aluminium wire separator or electric wire reparator, and also can be used as PCB recycling machine, Printed Circuit Boards recycling equipment.Waste wire recycling machine is a kind of environmental protection machine used to recyle waste electric wire, copper wire, aluminium wire, metallic composite wires and sheathed lines.
Through crude crushing, iron removal, fine crushing, gravity separation, electrostatic separation process to make completely dry and physical separation of scrap wires to get pure plastics and metal for double recycling and high benefit. Equipped with the electrostatic separator, it can make metal recovery rate get close to 100%.
2.Waste wire recycling machine Application
Waste wire recycling machine Application to All kinds of scrap wires, copper wire, aluminium wire, such as automobile electric line, motorcycle electric line, storage battery electric line, waste household appliance disassembly electric line, electromechanical equipment disassembly electric line, computer cable, telephone wire, cable TV line, communication cable and other scrap wires which are difficult to recycle, circuit board, copper-clad plate, etc.
3.Waste wire recycling machine features
Waste wire recycling machine
1.Low rotation rate,low noise and large moment of torsion.
2.Using electrical control security design to ensure the safety of operators.
3.Special designed cutter with high strength and long service life.
4.Can be customized according to customer's special requests.
5.High capacity and stable performance.
4.Waste wire recycling machine technical Parameters
|
Waste wire recycling machine |
|
Model |
power(kw) |
Capacity(T/H) |
Dimension(m) |
Package size |
Weight(T) |
|
DYTM-400 |
15 |
0.1-0.2 |
1.85*1.85*2 |
2*2*2.2 |
1.2 |
|
DYTM-600 |
45 |
0.2-0.3 |
3.5*2.2*2.55 |
3.85*2.28*2.36 |
3.0 |
|
DYTM-800 |
60 |
0.5-0.7 |
4*2.6*3.2 |
4.3*2.8*3.5 |
4.2 |
|
DYTM-1000 |
80 |
0.8-1.0 |
4.2*3*3.5 |
4.5*3*3.5 |
4.5 |
5.Waste wire recycling machine flow chart
